Product Model
|
Film screen P4-8
|
Film screen P5
|
Film screen P6.5
|
Film screen P5-10
|
Film screen P10
|
Film screen P16
|
Film screen P20
|
|
pixel pitch
|
4-8mm
|
5mm
|
6.5mm
|
5-10mm
|
10mm
|
16mm
|
20mm
|
|
pixel density
|
31250 points per square meter
|
40000 points per square meter
|
23668 points per square meter
|
20000 points per square meter
|
10000 points per square meter
|
3906 points per square meter
|
2500 points per square meter
|
|
Pixel composition
|
One pure red tube, one pure green tube, one pure blue tube
|
|
Display thickness
|
4mm
|
|
LED luminous tube
|
SMD2121
|
|
Driver IC
|
Integrated light drive (customized)
|
|
module dimensions
|
Height 960 * Width 64mm
|
Length 960 * Width 40mm
|
Length 962 * Width 52mm
|
Length 960 * Width 80mm
|
Length 960 * Width 80mm
|
Length 960 * Width 64mm
|
Length 960 * Width 80mm
|
|
box dimensions
|
Height 960 * Width 256mm or customized
|
Length 960 * Width 320mm or customized
|
Length 962 * Width 208mm or customized
|
Length 960 * Width 320mm or customized
|
960 * 320mm in length or customized
|
960*256mm
|
Length 960 * Width 320mm or customized
|
|
power consumption
|
Average: 200W/㎡, maximum: 800W/㎡
|
Average: 150W/㎡, maximum: 700W/㎡
|
Average: 200W/㎡, maximum: 800W/㎡
|
Average: 150W/㎡, maximum: 700W/㎡
|
Average: 150W/㎡, maximum: 700W/㎡
|
Average: 120W/㎡, maximum: 400W/㎡
|
Average: 100W/㎡, maximum: 300W/㎡
|
|
Screen weight
|
6kg/㎡
|
|
power supply
|
Yuanchi 400W (with PFC)
|
Yuanchi 400W (with PFC)
|
Yuanchi 400W (with PFC)
|
Yuanchi 400W (with PFC)
|
Yuanchi 400W (with PFC)
|
Yuanchi 300W (with PFC)
|
Yuanchi 300W (with PFC)
|
|
connector
|
copper material
|
|
wire and cable
|
National standard multi-core wire, certified
|
|
PCB board
|
International A material
|
|
Screen transparency
|
60%
|
50%
|
55%
|
80%
|
85%
|
85%
|
90%
|
|
Protection level
|
IP30
|
IP30/65
|
IP30
|
IP30/65
|
IP30/65
|
IP30/65
|
IP30/65
|
|
flatness
|
The joint between modules is less than 0.1mm
|
|
average life expectancy
|
More than 100000 usage hours
|
|
Out of control point
|
Less than one ten thousandth (when used continuously)
|
|
Power supply requirements
|
220V±10%； AC50HZ， three-phase five-wire
|
|
Continuous working hours
|
More than 72 hours
|
|
warranty period
|
one year
|
|
screen brightness
|
5000cd/m²
|
5000cd/m²
|
5000cd/m²
|
5000cd/m²
|
5000cd/m²
|
3000cd/m²
|
2500cd/m²
|
|
visual range
|
When viewed from a distance of 4m to 100m, the image is clear and visible
|
When viewed from a distance of 5m to 100m, the image is clear and visible
|
When viewed from a distance of 6.5m to 100m, the image is clear and visible
|
When viewed from a distance of 5m to 100m, the image is clear and visible
|
When viewed from a distance of 10m to 100m, the image is clear and visible
|
When viewed from a distance of 16m-100m, the image is clear and visible
|
When viewed from a distance of 20m to 100m, the image is clear and visible
|
|
Light emitting components
|
Guoxing, Huacaiwei
|
screen
|
Guoxing, Huacaiwei
|
Guoxing, Huacaiwei
|
Guoxing, Huacaiwei
|
Guoxing, Huacaiwei
|
Guoxing, Huacaiwei
|
|
brightness adjustment
|
Automatically adjust and manually adjust according to the ambient brightness, with levels greater than or equal to 256
|
|
perspective
|
Horizontal 140, vertical 140
|
|
gray level
|
65536 level grayscale
|
|
White field color temperature
|
5500K-9300K
|
|
image adjustment
|
White balance, contrast, visual, tone adjustment
|
|
image processing
|
The image has noise reduction, enhancement, motion compensation, and color coordinate transformation processing
|
|
Drive Type
|
constant current drive
|
|
scanning method
|
static
|
|
earth leakage current
|
Less than 2 milliamps
|
|
Signal processing capability
|
16bit
|
|
luminance uniformity
|
When the monochrome brightness of the entire screen is at its brightest, the minimum pixel brightness/maximum pixel brightness is greater than 0.95
|
|
attenuation rate
|
Less than 0.05% in 2 years
|
|
contrast
|
2000：1
|
|
refresh rate
|
3840HZ
|
|
frame rate
|
Greater than 60Hz
|
|
video input
|
Compatible with PAL/NTSC TV signals, compatible with HDTV and SDTV
|
|
software interface
|
WINDOWS7、NT、XP、2000
|
|
display mode
|
32-bit true color 1024X768
|
|
Mean time between failures
|
More than 10000 hours
|
|
Lamp bead defect rate
|
Less than one ten thousandth and distributed discretely
|
|
control system
|
Kalet, Mosier, Nova synchronous/asynchronous
|
|
Using a ring mirror
|
Working environment: -10~65 ℃/10~90% RH
Storage environment: -40~85 ℃/10~90% RH
|
|
certification
|
3C、CE、FCC
|
|
Installation method
|
Mounting, lifting, fixing, supporting cutting and bending of any size.
|
